2.4/2.7 Able Locking Plate System(ALPS)
Specification of 2.4/2.7 Able Locking Straight Plate(ALSP)
Unit : mm
Product Name Width Thickness Screw
2.4/2.7 ALSP(6.0x2.3T) 6.0 2.3 Ø 2.4/2.7 Cortical,
Ø 2.4/2.7 Locking,
Ø 2.7 Plug
2.4/2.7 ALSP(7.0x2.7T) 7.0 2.7
2.4/2.7 ALSP(8.0x3.0T) 8.0 3.0
Specification of 2.4/2.7 ALPS  Screw & Drill Bit
Unit : mm
Category Cortical Locking
2.4 2.7 2.4 2.7
Thread Dia. 2.4 2.7 2.4 2.7
Screw Length 8 / 10 / 12 / 14 / 16 / 18 / 20 / 22 / 24 / 26 / 28 / 30 / 32 / 34 / 36
Drill Bit Dia. 1.8 2.0 1.8 2.0
Driver Type T8 Star
Plate can use 2.4/2.7 ALPS Cortical & Locking Screw
2.4/2.7 Cortical & Locking Screw (4 types) can be used on the plate.
Cutting and bending of 2.4/2.7 ALPS  Plate
The plate can be cutting and bending according to the usage environment.
[ Repeated and excessive bending causes plate fracture. ]
1. Cutting
After fixing the cutting part with a cutter, twist and cut it.
2. Horizontal Bending
Bending within 3º between holes
3. Vertical Bending
Bending within 3º between holes
Bending within 3º between holes
Bending within 3º between holes
4. Twist Bending
2.4/2.7 ALPS  Locking Plug
It improves bending strength of the plate, and makes using simple fixation with Bone holding forceps and K-wire.
Increasing strength when placing the hole on fracture line.
Easy to fix forceps
Simple fixation with Ø1.6mm K-wire
Method to use 2.4/2.7 ALPS  Drill Guide & Drill Bit Stopper
It is possible to cut the bone by adjusting the bone cutting depth.
1. Checking the perforating depth (bone diameter)
2. Checking the protrusion length of the drill bit
3. Drilling
2.4/2.7 ALPS  Depth Gauge
The damaged pin can be replaced.
Medical biocompatible materials
It is produced using the approved Biomedical Stainless Steel & Titanium Alloy Alloys.
